In the previous post, we looked at Resources in the Model Context Protocol (MCP): how LLMs can securely access real-world data to ground their understanding. But sometimes, reading isn’t enough.

Sometimes, you want the model to do something.

That’s where Tools in MCP come in.

In this post, we’ll explore:

What tools are in MCP
How tools are discovered and invoked
How LLMs can use tools (with user control)
Common tool patterns and security practices
Real-world examples: from file system commands to API wrappers

Let’s dive in.

What Are Tools in MCP?

Tools are executable functions that an LLM (or the user) can call via the MCP client. Unlike resources: which are passive data, tools are active operations.

Examples include:

Running a shell command
Calling a REST API
Summarizing a document
Posting a GitHub issue
Triggering a build process

Each tool includes:

A name (unique identifier)
A description (for UI/model understanding)
An input schema (JSON schema describing expected parameters)

Tools allow models to interact with the world beyond natural language - under user oversight.

Discovering Tools

Clients can list available tools via: tools/list

Example response:

{
 "tools": [
 {
 "name": "calculate_sum", "description": "Add two numbers together", "inputSchema": {
 "type": "object", "properties": {
 "a": { "type": "number" }, "b": { "type": "number" }
 }, "required": ["a", "b"]
 }
 }
 ]
}

This allows clients (and LLMs) to decide which tools are available and how to call them properly.

⚙️ Calling a Tool

To execute a tool, the client sends:

tools/call

With this payload:

{
 "name": "calculate_sum", "arguments": {
 "a": 3, "b": 5
 }
}

The server responds with:

{
 "content": [
 {
 "type": "text", "text": "8"
 }
 ]
}

That’s it! The LLM can now use this output in a multi-step reasoning chain.

Model-Controlled Tool Use

Tools are designed to be invoked by models automatically. The host mediates this interaction with:

Approval flows (user-in-the-loop)
Permission gating
Logging and auditing

This is what enables “agentic behavior.” For example:

Claude sees a CSV file and decides to call analyze_csv to compute averages - without a user explicitly requesting it.

Tool Design Patterns

Let’s look at some common and powerful tool types:

System Tools

{
 "name": "run_command", "description": "Execute a shell command", "inputSchema": {
 "type": "object", "properties": {
 "command": { "type": "string" }, "args": {
 "type": "array", "items": { "type": "string" }
 }
 }
 }
}

Use case: Let the LLM grep a log file, or check system uptime.

API Integrations

{
 "name": "create_github_issue", "description": "Open a new issue on GitHub", "inputSchema": {
 "type": "object", "properties": {
 "repo": { "type": "string" }, "title": { "type": "string" }, "body": { "type": "string" }
 }
 }
}

Use case: Let an AI dev assistant file bugs or suggest changes.

Data Analysis

{
 "name": "summarize_csv", "description": "Summarize a CSV file", "inputSchema": {
 "type": "object", "properties": {
 "filepath": { "type": "string" }
 }
 }
}

Use case: Let the LLM analyze performance metrics or user data.

Security Best Practices

Giving LLMs the ability to take action means security is critical. Here’s how to stay safe:

Validate all input Use detailed JSON schemas

Sanitize input (e.g., file paths, commands)

Use access controls Gate sensitive tools behind roles

Allow user opt-in or approval

Log and monitor usage Track which tools are used, with what arguments

Log errors and output for audit trails

Handle errors gracefully Return structured errors inside the result, not just raw exceptions. This helps the LLM adapt.

{
 "isError": true, "content": [
 {
 "type": "text", "text": "Error: File not found."
 }
 ]
}

Example: Implementing a Tool Server in Python

@mcp.tool()
async def get_weather(city: str) -> str:
 """Return current weather for a city."""
 data = await fetch_weather(city)
 return f"The temperature in {city} is {data['temp']}°C."

This tool will automatically appear in the tools/list response and can be invoked by the LLM or user.

Why Tools Matter for Agents

Agents aren’t just chatbots - they’re interactive systems. Tools give them the ability to:

Take real-world actions
Build dynamic workflows
Chain reasoning across multiple steps
Drive automation in safe, auditable ways

Combined with resources, prompts, and sampling, tools make LLMs feel like collaborative assistants, not just text predictors.

Tool Concepts Overview

Concept	Description
Tool definition	Name, description, and input schema
Invocation	`tools/call` with arguments
Output	Text or structured response
Use case examples	Shell commands, API calls, code generation, analysis
Security guidelines	Validate input, log usage, gate sensitive actions

Coming Up Next: Sampling and Prompts : Letting the Server Ask the Model for Help

In the final two posts of this series, we’ll explore:

✅ Sampling : How servers can request completions from the LLM during workflows ✅ Prompts : Reusable templates for user-driven or model-driven actions

Tools give LLMs the power to act. With proper controls and schemas, they become safe, composable building blocks for real-world automation.
